XK-9060 CO2 laser cutting machine
Xunke
Cutting Engraving
Acrylic Wood Stone Other
Advertising industry
9060 CO2 Laser Cutting Machine
9060 CO2 laser cutting machine used in advertising or handicraft industry.
It is equipped with step motor for working efficiency and precision, heavy machine body for stable working
CO2 laser cutting machine is used widly to cut and engrave wood, MDF, plywood, PVC acrylic, paper, fabric, stone and soft materials through CO2 laser cutting technology, it has wide applications in advertising industry, garment industry and so on.
Model | XK-9060 | Power supply | |
Machine Size | 2200*1200*800mm | Drive | step motor and dirve(customized) |
Working area | 1300*900mm | Control system | NC Studio/Syntec/DSP |
Gantry | Square gantry with Cast iron side panels | Motor | Step motor |
Laser tube | Chendu Weiju | Platform | Blade |
Laser power | 80w-150w | Cabinet | Industrial grade anti-interference cabinet |
Driving mode | Belt and guide rail | Voltage | 220V/380V |
Rail | 20 linear square rail | Accuracy | ±0.02mm |
Warranty | 1 year | Operation Code | G Code(*.nc.*.mmg.*.u00,etc.),eng |
Software | CAD/CAM(Window98/XP/7/8/10 ) | ||
Application | Cutting with CCD, acrylic, luminous word, advertising signs |
High quality laser tube: we choose a laser tube with high quality, which ensures the cutting and engraving effciency, it is in high stability and durability.
Identify different formats: it can identify multiple formats, such as PLT, DXF, BMP, etc.
Heavy machine body
Equipped with CCD Camera
Slected high-power laser tube-light stability, continuous light does not decay long life
Large screen operation panel, direct preview of processing graphics, more convenient operation
A:Yes, this machine can cut a little metal, it had better choose mixed laser head.
A:There's a possibility, we need adjust the parameters to the appropriate laser cutting parameters togother with suitable lens, air compressor can be used when necessary, This can effectively avoid the situation of burning the material.
24/7 online after sales service! |
Complete quality control process! |
OEM&Customization! |
Welcome to visit our company! |
